2010 Outlander 650 EFI
Engine
	Type	649.6 cc, V-twin, liquid-cooled, SOHC, 8-valve (4-valve / cyl)
	Bore & Stroke	82 x 62 mm
	EFI System / Carburetor	46-mm Throttle Body, 2 Siemens VDO injectors
	Starting System	Electric
	Transmission	CVT, sub-transmission with high, low, park, neutral & reverse, standard engine braking
	Drive Train	Selectable 2w/4w shaft driven with Visco-lok† front differential
Chassis
	Frame	SST
	Front Suspension Type	Double A-arm
	Travel	8 in (203 mm)
	Rear Suspension Type	TTI independent
	Travel	9 in (229 mm)
	Front Brake	2 inboard hydraulic discs
	Rear Brake	1 inboard hydraulic disc
	Tires/Front	26 x 8 x 12 in 660 x 203 x 305 mm
	Tires/Rear	26 x 10 x 12 in 660 x 254 x 305 mm
	Wheels	Cast-aluminum wheels
Dimensions
	LxWxH (in)	86 x 46 x 45 in
	LxWxH (mm)	2,184 x 1,168 x 1,143 mm
	Wheel Base	51 in (1,295 mm)
	Seat Height	34.5 in (877 mm)
	Ground Clearance	12 in (305 mm)
	Dry Weight	669 lbs (303 kg)
	Towing Capacity	1,300 lbs (590 kg)
	Rack Capacity	100 lbs (45 kg) 200 lbs (90 kg)
	Storage	Rear storage 5.3 US gal (20 L)
	Fuel Capacity	4.3 US gal. (16.3 L)
Features
	Instrumentation	Multi-function digital LCD gauge : speedometer, tachometer (bar graph RPM, bottom bar numerical RPM), odometer, trip & hour meter, diagnostic center, gear position, engine hour meter, 4x4 indicator, temperature and engine lights, fuel gauge, auto shut off after 15 minutes
	Anti-Theft	Digitally Encoded Security System (D.E.S.S.)
	Electrical	Prewired for winch
	Lighting	2 fender mounted headlamps (35W) with tail light / brake light
	DS Outlet	Lighter type in console, standard connector in the back (15A)
	Color(s) Available	Yellow, Viper Red
	MSRP	$9,249 US
